Hitachi KOE TX26D211VM0BAB 10.4" IPS LCM 1024×768 1300nits WLED LVDS 20pins

Hitachi KOE TX26D211VM0BAB 10.4" IPS LCM 1024768 1300nits WLED LVDS 20pinsS

Product Description

Hitachi KOE TX26D211VM0BAB 10.4" IPS LCM 1024×768 1300nits WLED LVDS 20pins

System Category :	LCD/OLED/EPD Flat Panel > TFT-LCD Panel
Brand :	KOE
Series :	TX26D211
Model :	TX26D211VM0BAB
Keywords Desc. :	KOE 10.4" IPS LCM 1024×768 1300nits WLED LVDS 20pins
Product Class :	Graphic Display
Product Tags :	Color TFT-LCD, Wide Temperature LCD, High Brightness LCD, Sunlight Readable LCD, IPS LCD
Application :	Industrial, Outdoor High Brightness, Rugged Industry
Panel Type :	a-Si TFT-LCD
Panel Composition :	LCM
Panel Size :	10.4"
Resolution :	1024×768
Aspect Ratio :	4:3 (W:H)
Form Factor :	Flat Rectangle
Active Area :	211.2 (W) × 158.4 (H) mm (A.A)
Outline Dimension :	230 (W) × 180.2 (H) mm
Max. Depth :	10 mm
LC Family :	IPS
Polarizer :	Transmissive
Brightness :	1300 (Typ.)
Contrast Ratio :	1000:1 (Typ.)
Viewing Angle :	85/85/85/85 (Typ.)(CR≥10) (L/R/U/D)
Viewing Direction :	Symmetry
Display Colors :	16.7M
Backlight Type :	WLED
Interface Type :	LVDS
Interface Pins :	20 Pins
Touch Panel :	Without
Operating Temp. :	-30 ~ 80 °C
Storage Temp. :	-40 ~ 80 °C
