AUO G101UAN04.0 10.1" IPS LCD Panel 1200×1920 500nits WLED MIPI 40pins Display Screen

AUO 10.1" IPS LCM 12001920 500nits WLED MIPI 40pinsSystem Category :LCD/OLE

Product Description

System Category :	LCD/OLED/EPD Flat Panel > TFT-LCD Panel
Brand :	AUO
Series :	G101UAN04
Model :	G101UAN04.0
Keywords Desc. :	AUO 10.1" IPS LCM 1200×1920 500nits WLED MIPI 40pins
Product Class :	Graphic Display
Product Tags :	Color TFT-LCD, IPS LCD
Application :	Industrial
Panel Type :	a-Si TFT-LCD
Panel Composition :	LCM
Panel Size :	10.1"
Resolution :	1200×1920
Aspect Ratio :	10:16 (W:H)
Form Factor :	Flat Rectangle
Active Area :	135.36 (W) × 216.58 (H) mm (A.A)
Outline Dimension :	142 (W) × 228.55 (H) mm
Max. Depth :	5.36 mm
LC Family :	IPS
Polarizer :	Transmissive
Brightness :	500 (Typ.)
Contrast Ratio :	900:1 (Typ.)
Viewing Angle :	89/89/89/89 (Typ.)(CR≥10) (L/R/U/D)
Viewing Direction :	Symmetry
Display Colors :	16.7M
Backlight Type :	WLED
Interface Type :	MIPI
Interface Pins :	40 Pins
Touch Panel :	Without
Operating Temp. :	0 ~ 50 °C
Storage Temp. :	-20 ~ 60 °C
