AUO G156HAN05.1 15.6" IPS LCD Display Screen 1920×1080 300nits WLED eDP 30pins

AUO 15.6" IPS LCM 19201080 300nits WLED eDP 30pinsSystem Category :LCD/OLED

Product Description

System Category :	LCD/OLED/EPD Flat Panel > TFT-LCD Panel
Brand :	AUO
Series :	G156HAN05
Model :	G156HAN05.1
Keywords Desc. :	AUO 15.6" IPS LCM 1920×1080 300nits WLED eDP 30pins
Product Class :	Graphic Display
Product Tags :	Color TFT-LCD, IPS LCD
Application :	Industrial
Panel Type :	a-Si TFT-LCD
Panel Composition :	LCM
Panel Size :	15.6"
Resolution :	1920×1080
Aspect Ratio :	16:9 (W:H)
Form Factor :	Flat Rectangle
Active Area :	344.16 (W) × 193.59 (H) mm (A.A)
Outline Dimension :	350.66 (W) × 205.24 (H) mm
Max. Depth :	5.4 mm
LC Family :	IPS
Polarizer :	Transmissive
Brightness :	300 (Typ.)
Contrast Ratio :	800:1 (Typ.)
Viewing Angle :	85/85/85/85 (Typ.)(CR≥10) (L/R/U/D)
Viewing Direction :	Symmetry
Display Colors :	16.2M
Backlight Type :	WLED
Interface Type :	eDP
Interface Pins :	30 Pins
Touch Panel :	Without
Operating Temp. :	0 ~ 50 °C
Storage Temp. :	-20 ~ 60 °C
