G270ZAN02.1 Lcd Screen AUO 27inch UHD 3840x2160 850 nits 0~50°C 30K DCIP3 98% eDP 8bit+Hi-FRC w/o D 2000:1 Glare type

$0

G270ZAN02.1 Lcd Screen AUO 27inch UHD 3840x2160 850 nits 0~50C 30K DCIP3 98% eDP

Product Description

G270ZAN02.1 Lcd Screen AUO 27inch UHD 3840x2160 850 nits 0~50°C 30K DCIP3 98% eDP 8bit+Hi-FRC w/o D 2000:1 Glare type


  • Brand
  • AUO
  • Model P/N
  • G270ZAN02.1
  • Diagonal Size
  • 27.0"
  • Panel Type
  • a-Si TFT-LCD, LCM
  • Resolution
  • 3840(RGB)×2160, UHD  163PPI
  • Pixel Format
  • RGB Vertical Stripe
  • Active Area
  • 596.16(W)×335.34(H) mm
  • Bezel Opening
  • 602(W)×340.4(H) mm
Outline Dim.630(H)×368.2(V) ×19.8(D) mmTreatmentGlare (Haze 0%)
Luminance850 cd/m² (Typ.)Contrast Ratio2000:1 (Typ.) (TM)
View DirectionSymmetryResponse Time10/12 (Typ.)(Tr/Td)
Viewing Angle89/89/89/89 (Typ.)(CR≥10) Operating ModeAHVA, Normally Black, Transmissive
Support Color1.07B   98% DCI-P3Light SourceWLED , 30K hours , W/O Driver
Weight3.20/3.36Kgs (Typ./Max.)Designed For
  •
  •
Frame Rate60Hz  Touch PanelWithout
Interface TypeeDP (4 Lanes) , HBR2 (5.4G/lane) , 51 pins Connector
Power Supply12.0V (Typ.)
EnvironmentOperating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C

AUO G270ZAN02.1 Mechanical Features

Panel Size :27.0"
Pixel Features :Pixel FormatPixel ConfigurationPixel Pitch (mm)Dot Pitch (mm)
3840(RGB)×2160 [UHD]RGB Vertical Stripe0.15525×0.15525  [163PPI]0.05175×0.15525
Mechanical Size :Active Area (mm)Bezel Area (mm)Outline Dimension (mm)Outline Depth (mm)
596.16(H) × 335.34(V)602(H) × 340.4(V)630(H) × 368.2(V)19.3±0.5 mm
Outline Features :Form FactorOrientationAspect RatioShape Style
Flat RectangleLandscape type16:9 (H:V)
Mounting :Side mounting holes (4-M3) on left, right bezel
Other Detail :WeightPanel CoverTreatment
3.20/3.36Kgs (Typ./Max.)-Glare (Haze 0%)
  • Disclaimer : Inputted by panelook engineers according to datasheet, but we cannot guarantee the spec listed is entirely correct.
  •  Back to Top

AUO G270ZAN02.1 Optical Features

Basic Information :Luminance (cd/m²)Viewing Angle (L/R/U/D)Response Time (ms)
850 (Typ.)89/89/89/89 (Typ.)(CR≥10)10/12 (Typ.)(Tr/Td)
Best View onDisplay ModeContrast Ratio
SymmetryAHVA, Normally Black, Transmissive2000 : 1 (Typ.) (Transmissive)
Dispaly Color :Color TemperatureDisplay ColorsWhite Coordinate
6485K1.07B (8-bit + Hi-FRC)X:0.313; Y:0.329
1931 Color Gamut :NTSC RatiosRGB CoverageAdobe RGB Coverage
104%100%94%
DCI-P3 CoverageRec.2020 CoverageRemarks
99%78%sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)
White Variation :1.25/1.33 (Typ./Max.)(9 points)
Performance :3D TechSunlight VisibilityReflectance
-Sunlight Readable-
