G101UAN01.0 AUO 10.1" IPS LCD Panel 1920×1200 380nits WLED eDP 30pins Screen

G101UAN01.0 AUO 10.1" IPS LCD Panel 19201200 380nits WLED eDP 30pins Screen

Product Description

System Category :	LCD/OLED/EPD Flat Panel > TFT-LCD Panel
Brand :	AUO
Series :	G101UAN01
Model :	G101UAN01.0
Keywords Desc. :	AUO 10.1" IPS LCM 1920×1200 380nits WLED eDP 30pins
Product Class :	Graphic Display
Product Tags :	Color TFT-LCD, IPS LCD
Application :	Industrial
Panel Type :	a-Si TFT-LCD
Panel Composition :	LCM
Panel Size :	10.1"
Resolution :	1920×1200
Aspect Ratio :	16:10 (W:H)
Form Factor :	Flat Rectangle
Active Area :	216.81 (W) × 135.5 (H) mm (A.A)
Outline Dimension :	227.72 (W) × 147.8 (H) mm
Max. Depth :	5.35 mm
LC Family :	IPS
Polarizer :	Transmissive
Brightness :	380 (Typ.)
Contrast Ratio :	800:1 (Typ.)
Viewing Angle :	89/89/89/89 (Typ.)(CR≥10) (L/R/U/D)
Viewing Direction :	Symmetry
Display Colors :	16.7M
Backlight Type :	WLED
Interface Type :	eDP
Interface Pins :	30 Pins
Touch Panel :	Without
Operating Temp. :	-10 ~ 60 °C
Storage Temp. :	-20 ~ 60 °C
