G170ETN01.0 AUO 17" TN LCD Panel 1280×1024 350nits WLED LVDS 30pins Screen

G170ETN01.0 AUO 17" TN LCD Panel 12801024 350nits WLED LVDS 30pins Screen

Product Description

System Category :	LCD/OLED/EPD Flat Panel > TFT-LCD Panel
Brand :	AUO
Series :	G170ETN01
Model :	G170ETN01.0
Keywords Desc. :	AUO 17" TN LCM 1280×1024 350nits WLED LVDS 30pins
Product Class :	Graphic Display
Product Tags :	Color TFT-LCD
Application :	Industrial
Panel Type :	a-Si TFT-LCD
Panel Composition :	LCM
Panel Size :	17"
Resolution :	1280×1024
Aspect Ratio :	5:4 (W:H)
Form Factor :	Flat Rectangle
Active Area :	337.92 (W) × 270.336 (H) mm (A.A)
Outline Dimension :	358.5 (W) × 296.5 (H) mm
Max. Depth :	18 mm
LC Family :	TN
Polarizer :	Transmissive
Brightness :	350 (Typ.)
Contrast Ratio :	1000:1 (Typ.)
Viewing Angle :	85/85/80/80 (Typ.)(CR≥10) (L/R/U/D)
Display Colors :	16.7M
Backlight Type :	WLED
Interface Type :	LVDS
Interface Pins :	30 Pins
Touch Panel :	Without
Operating Temp. :	0 ~ 50 °C
Storage Temp. :	-20 ~ 60 °C
