G156HAT01.0 AUO 15.6" IPS LCD Panel 1920×1080 425nits WLED eDP 30pins CTP

G156HAT01.0 AUO 15.6" IPS LCD Panel 19201080 425nits WLED eDP 30pins CTPSpe

Product Description

System Category :	LCD/OLED/EPD Flat Panel > TFT-LCD Panel
Brand :	AUO
Series :	G156HAT01
Model :	G156HAT01.0
Keywords Desc. :	AUO 15.6" IPS LCM 1920×1080 425nits WLED eDP 30pins CTP AUO30ED
Product Class :	Graphic Display
Product Tags :	Color TFT-LCD, Capacitive Touch LCD, IPS LCD
Application :	Industrial
Panel Type :	a-Si TFT-LCD
Panel Composition :	LCM
Panel Size :	15.6"
Resolution :	1920×1080
Aspect Ratio :	16:9 (W:H)
Form Factor :	Flat Rectangle
Active Area :	344.16 (W) × 193.59 (H) mm (A.A)
Outline Dimension :	370.4 (W) × 227.89 (H) mm
Max. Depth :	13.78 mm
LC Family :	IPS
Polarizer :	Transmissive
Brightness :	425 (Typ.)
Contrast Ratio :	800:1 (Typ.)
Viewing Angle :	89/89/89/89 (Typ.)(CR≥10) (L/R/U/D)
Viewing Direction :	Symmetry
Display Colors :	16.2M
Backlight Type :	WLED
Interface Type :	eDP
Interface Pins :	30 Pins
Touch Panel :	PCAP, Air Bonding
Operating Temp. :	-10 ~ 60 °C
Storage Temp. :	-10 ~ 60 °C
