G150XAN02.2 AUO 15" IPS LCD Panel 1024×768 1800nits WLED LVDS 20pins

G150XAN02.2 AUO 15" IPS LCD Panel 1024768 1800nits WLED LVDS 20pinsSpecific

Product Description

System Category :	LCD/OLED/EPD Flat Panel > TFT-LCD Panel
Brand :	AUO
Series :	G150XAN02
Model :	G150XAN02.2
Keywords Desc. :	AUO 15" IPS LCM 1024×768 1800nits WLED LVDS 20pins
Product Class :	Graphic Display
Product Tags :	Color TFT-LCD, Wide Temperature LCD, High Brightness LCD, Sunlight Readable LCD, IPS LCD
Application :	Industrial
Panel Type :	a-Si TFT-LCD
Panel Composition :	LCM
Panel Size :	15"
Resolution :	1024×768
Aspect Ratio :	4:3 (W:H)
Form Factor :	Flat Rectangle
Active Area :	304.128 (W) × 228.096 (H) mm (A.A)
Outline Dimension :	326.5 (W) × 253.5 (H) mm
Max. Depth :	9.8 mm
LC Family :	IPS
Polarizer :	Transmissive
Brightness :	1800 (Typ.)
Contrast Ratio :	1000:1 (Typ.)
Viewing Angle :	89/89/89/89 (Typ.)(CR≥10) (L/R/U/D)
Viewing Direction :	Symmetry
Display Colors :	16.2M
Backlight Type :	WLED
Interface Type :	LVDS
Interface Pins :	20 Pins
Touch Panel :	Without
Operating Temp. :	-30 ~ 70 °C
Storage Temp. :	-30 ~ 70 °C
