G121STN02.1 AUO 12.1" TN LCD Panel 800×600 1500nits WLED LVDS 20pins Screen

G121STN02.1 AUO 12.1" TN LCD Panel 800600 1500nits WLED LVDS 20pins ScreenS

Product Description

System Category :	LCD/OLED/EPD Flat Panel > TFT-LCD Panel
Brand :	AUO
Series :	G121STN02
Model :	G121STN02.1
Keywords Desc. :	AUO 12.1" TN LCM 800×600 1500nits WLED LVDS 20pins
Product Class :	Graphic Display
Product Tags :	Color TFT-LCD, Wide Temperature LCD, High Brightness LCD, Sunlight Readable LCD
Application :	Industrial
Panel Type :	a-Si TFT-LCD
Panel Composition :	LCM
Panel Size :	12.1"
Resolution :	800×600
Aspect Ratio :	4:3 (W:H)
Form Factor :	Flat Rectangle
Active Area :	246 (W) × 184.5 (H) mm (A.A)
Outline Dimension :	261.65 (W) × 203 (H) mm
Max. Depth :	9 mm
LC Family :	TN
Polarizer :	Transmissive
Brightness :	1500 (Typ.)
Contrast Ratio :	800:1 (Typ.)
Viewing Angle :	80/80/65/75 (Typ.)(CR≥10) (L/R/U/D)
Viewing Direction :	6 o'clock
Display Colors :	262K/16.7M
Backlight Type :	WLED
Interface Type :	LVDS
Interface Pins :	20 Pins
Touch Panel :	Without
Operating Temp. :	-30 ~ 85 °C
Storage Temp. :	-30 ~ 85 °C
