G133HAN02.2 AUO 13.3" IPS LCD 1920×1080 500nits WLED eDP 30pins Display Screen

G133HAN02.2 AUO 13.3" IPS LCD 19201080 500nits WLED eDP 30pins Display Scre

Product Description

System Category :	LCD/OLED/EPD Flat Panel > TFT-LCD Panel
Brand :	AUO
Series :	G133HAN02
Model :	G133HAN02.2
Keywords Desc. :	AUO 13.3" IPS LCM 1920×1080 500nits WLED eDP 30pins AUO222D
Product Class :	Graphic Display
Product Tags :	Color TFT-LCD, IPS LCD
Application :	Gaming, Healthcare, Industrial
Panel Type :	a-Si TFT-LCD
Panel Composition :	LCM
Panel Size :	13.3"
Resolution :	1920×1080
Aspect Ratio :	16:9 (W:H)
Form Factor :	Flat Rectangle
Active Area :	293.472 (W) × 165.078 (H) mm (A.A)
Outline Dimension :	306.3 (W) × 195.29 (H) mm
Max. Depth :	3.2 mm
LC Family :	IPS
Polarizer :	Transmissive
Brightness :	500 (Typ.)
Contrast Ratio :	800:1 (Typ.)
Viewing Angle :	89/89/89/89 (Typ.)(CR≥10) (L/R/U/D)
Viewing Direction :	Symmetry
Display Colors :	16.2M
Backlight Type :	WLED
Interface Type :	eDP
Interface Pins :	30 Pins
Touch Panel :	Without
Operating Temp. :	0 ~ 60 °C
Storage Temp. :	-20 ~ 60 °C
