AUO P215HVN02.1 21.5" VA LCM 1920×1080 300nits WLED LVDS 30pins

AUO P215HVN02.1 21.5" VA LCM 19201080 300nits WLED LVDS 30pinsSpecification

Product Description

AUO P215HVN02.1 21.5" VA LCM 1920×1080 300nits WLED LVDS 30pins

System Category :	LCD/OLED/EPD Flat Panel > TFT-LCD Panel
Brand :	AUO
Series :	P215HVN02
Model :	P215HVN02.1
Keywords Desc. :	AUO 21.5" VA LCM 1920×1080 300nits WLED LVDS 30pins
Product Class :	Graphic Display
Product Tags :	Color TFT-LCD
Application :	Digital Signage
Panel Type :	a-Si TFT-LCD
Panel Composition :	LCM
Panel Size :	21.5"
Resolution :	1920×1080
Aspect Ratio :	17:9 (W:H)
Form Factor :	Flat Rectangle
Active Area :	478.656 (W) × 260.28 (H) mm (A.A)
Outline Dimension :	501.88 (W) × 284.78 (H) mm
Max. Depth :	12 mm
LC Family :	VA
Polarizer :	Transmissive
Brightness :	300 (Typ.)
Contrast Ratio :	3000:1 (Typ.)
Viewing Angle :	89/89/89/89 (Typ.)(CR≥10) (L/R/U/D)
Viewing Direction :	Symmetry
Display Colors :	16.7M
Backlight Type :	WLED
Interface Type :	LVDS
Interface Pins :	30 Pins
Touch Panel :	Without
Operating Temp. :	0 ~ 50 °C
Storage Temp. :	-20 ~ 60 °C
