SHARP LQ315D1VG01 32" VA LCM 3840×2160 700nits WLED V-by-One 51pins

SHARP LQ315D1VG01 32" VA LCM 38402160 700nits WLED V-by-One 51pinsSpecifica

Product Description

SHARP LQ315D1VG01 32" VA LCM 3840×2160 700nits WLED V-by-One 51pins

System Category :	LCD/OLED/EPD Flat Panel > TFT-LCD Panel
Brand :	Sharp
Series :	LQ315D1VG
Model :	LQ315D1VG01
Keywords Desc. :	Sharp 32" VA LCM 3840×2160 700nits WLED V-by-One 51pins
Product Class :	Graphic Display
Product Tags :	Color TFT-LCD, High Brightness LCD, Sunlight Readable LCD
Application :	Medical Imaging
Panel Type :	Oxide TFT-LCD
Panel Composition :	LCM
Panel Size :	32"
Resolution :	3840×2160
Aspect Ratio :	16:9 (W:H)
Form Factor :	Flat Rectangle
Active Area :	697.92 (W) × 392.58 (H) mm (A.A)
Outline Dimension :	734.8 (W) × 430 (H) mm
Max. Depth :	26.5 mm
LC Family :	VA
Polarizer :	Transmissive
Brightness :	700 (Typ.)
Contrast Ratio :	1000:1 (Typ.)
Viewing Angle :	89/89/89/89 (Typ.)(CR≥10) (L/R/U/D)
Viewing Direction :	Symmetry
Display Colors :	1.07B
Backlight Type :	WLED
Interface Type :	V-by-One
Interface Pins :	51 Pins
Touch Panel :	Without
Operating Temp. :	0 ~ 40 °C
Storage Temp. :	-25 ~ 60 °C
