LG 27inch 3840x2160 LM270WR8-SSA1 HDR600 DCI 98% 1000:1 8bF LBL Neo III 144Hz

$0

LG 27inch 3840x2160 LM270WR8-SSA1 HDR600 DCI 98% 1000:1 8bF LBL Neo III 144HzBra

Product Description

LG 27inch 3840x2160 LM270WR8-SSA1 HDR600 DCI 98% 1000:1 8bF LBL Neo III 144Hz


  • Brand
  • LG Display
  • Model P/N
  • LM270WR8-SSA1
  • Diagonal Size
  • 27.0"
  • Panel Type
  • Oxide TFT-LCD, LCM
  • Resolution
  • 3840(RGB)×2160, UHD  163PPI
  • Pixel Format
  • RGB Vertical Stripe
  • Active Area
  • 596.736(W)×335.664(H) mm
  • Bezel Opening
  • -
  • Outline Dim.
    603.9(W)×347.45(H)×15.8(D) mm
  • Treatment
    Antiglare (Haze 25%), Hard coating (3H)
  • Luminance
    450 cd/m² (Typ.)
  • Contrast Ratio
    1000:1 (Typ.) (TM)
  • View Direction
    Symmetry
  • Response Time
    5 (Typ.)(G to G)
  • Viewing Angle
    89/89/89/89 (Typ.)(CR≥10)
  • Operating Mode
    IPS, Normally Black, Transmissive
  • Support Color
    1.07B   97% DCI-P3
  • Light Source
    WLED , 30K hours , W/O Driver
  • Weight
    3.25/3.41Kgs (Typ.)
  • Designed For

  • Frame Rate
    144Hz
  • Touch Panel
    Without
  • Interface Type
  • eDP (16 Lanes) , HBR2 (5.4G/lane) , 120 pins Connector
  • Power Supply
  • 10.0V (Typ.)
  • Environment
  • Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C

  • LG Display LM270WR8-SSA1 Mechanical Details

    Pixel Features :
    Pixel Format
    3840(RGB)×2160, UHD
    Dot Pitch
    0.0518×0.1554 mm (H×V)
    Configuration
    RGB Vertical Stripe
    Pixel Pitch
    0.1554×0.1554 mm (H×V)  [163PPI]
    Mechanical Size :
    Display Area
    596.736×335.664 mm (H×V)
    Outline Dim.
    -
    Outline Dim.
    603.9×347.45 mm (H×V)
    Outline Depth
    6.9/15.8 (Typ./Max.) mm
    Outline Features :
    Form Factor
    Flat Rectangle
    Orientation
    Landscape type
    Aspect Ratio
    16:9 (H:V)
    Shape Style
    4-side borderless
    Holes & Brackets :
    Rear mounting holes
    Other Features :
    Weight
    3.25/3.41Kgs (Typ.)
    Surface
    Antiglare (Haze 25%), Hard coating (3H)
    • Disclaimer : Inputted by panelook engineers according to datasheet, but we cannot guarantee the spec listed is entirely correct.
    •  Back to Top

  • LG Display LM270WR8-SSA1 Optical Details

    Basic Information :
    Brightness
    450 cd/m² (Typ.), HDR600
    Contrast Ratio
    1000:1 (Typ.) (Transmissive)
    Viewing Angle
    89/89/89/89 (Typ.)(CR≥10)
    Optical Mode
    IPS, Normally Black, Transmissive
    Viewing Direction
    Symmetry
    Response Time
    5 (Typ.)(G to G) ms
    Color Performance :
    Chromaticity
    Wx:0.313; Wy:0.329
    Color Numbers
    1.07B (8-bit + Hi-FRC)
    Color Temperature
    6485K
    Uniformity
    1.33 (Max.)(9 points)
    1931 Color Gamut :
    NTSC Ratio
    94%
    sRGB
    100% coverage
    Adobe RGB
    87% coverage
    DCI-P3
    97% coverage
    Rec.2020
    71% coverage
    Remarks
    sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)
