Product Description

LG 31.5inch LB315WR6-SSZ1 3840x2160 1000nit sRGB 2000:1 8bF eDP Case Top font


  • Brand
  • LG Display
  • Model P/N
  • LB315WR6-SSZ1
  • Diagonal Size
  • 32.0"
  • Panel Type
  • a-Si TFT-LCD, LCM
  • Resolution
  • 3840(RGB)×2160, UHD  139PPI
  • Pixel Format
  • RGB Vertical Stripe
  • Active Area
  • 697.306(W)×392.234(H) mm
  • Bezel Opening
  • 701.7(W)×398.36(H) mm
  • Outline Dim.
  • 730.7(H)×425.2(V) ×23.7(D) mm
  • Treatment
  • Antiglare (Haze 25%), Hard coating (3H)
  • Luminance
  • 1000 cd/m² (Typ.)
  • Contrast Ratio
  • 2000:1 (Typ.) (TM)
  • View Direction
  • Symmetry
  • Response Time
  • 14 (Typ.)(G to G)
  • Viewing Angle
  • 89/89/89/89 (Typ.)(CR≥10)
  • Operating Mode
  • IPS, Normally Black, Transmissive
  • Support Color
  • 1.07B   100% sRGB
  • Light Source
  • WLED , 30K hours , W/O Driver
  • Weight
  • 5.90/6.20Kgs (Typ./Max.)
  • Designed For
  • Frame Rate
  • 60Hz
  • Touch Panel
  • Without
  • Interface Type
  • eDP (4 Lanes) , HBR2 (5.4G/lane) , 30 pins Connector
  • Power Supply
  • 10.0V (Typ.)
  • Environment
  • Operating Temperature: 5 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C

  • LG Display LB315WR6-SSZ1 Mechanical Features

    Panel Size :32.0 inch
    Pixel Features :ResolutionPixel ArrangementDot Pitch (W×H)Pixel Pitch (W×H)
    3840(RGB)×2160, UHDRGB Vertical Stripe0.06053×0.18159 mm0.18159×0.18159 mm  [139PPI]
    Mechanical Size :Active Area (W×H)Bezel Area (W×H)Outline Dimension (W×H)Outline Depth
    697.306×392.234 mm701.7×398.36 mm730.7×425.2 mm22.2/23.7 (Typ./Max.) mm
    Outline Features :Form StyleAspect RatioOrientationShape Style
    Flat Rectangle16:9 (W : H)Landscape type
    Fixation :Rear mounting holes
    Other Features :Panel CoverWeightSurface
    -5.90/6.20Kgs (Typ./Max.)Antiglare (Haze 25%), Hard coating (3H)
    • Disclaimer : Inputted by panelook engineers according to datasheet, but we cannot guarantee the spec listed is entirely correct.
    •  Back to Top

  • LG Display LB315WR6-SSZ1 Optical Features

    Basic Information :BrightnessOperating ModeContrast Ratio
    1000 cd/m² (Typ.)IPS, Normally Black, Transmissive2000:1 (Typ.) (Transmissive)
    Viewing Angle(L/R/U/D)Viewing DirectionResponse Speed
    89/89/89/89 (Typ.)(CR≥10)Symmetry14 (Typ.)(G to G) (ms)
    Dispaly Color :Color TemperatureColor AmountWhite color Chromaticity
    6485K1.07B (8-bit + Hi-FRC)X:0.313; Y:0.329
    1931 Color Gamut :NTSC RatiosRGB CoverageAdobe RGB Coverage
    85%100%83%
    DCI-P3 CoverageRec.2020 CoverageRemarks
    89%64%sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)
    Luminance Variation :1.33 (Max.)(9 points)
    Performance :3D TypeOutdoor VisibilityReflectance
    -Sunlight Readable-
