LG 31.5inch LM315WR4-SSA1 3840x2160 HDR 1000 DCI 98% 1300:1 8bF eDP Neo I 144Hz

$0

LG 31.5inch LM315WR4-SSA1 3840x2160 HDR 1000 DCI98% 1300:1 8bF eDP Neo I 144HzBr

Product Description

LG 31.5inch LM315WR4-SSA1 3840x2160 HDR 1000 DCI 98% 1300:1 8bF eDP Neo I 144Hz



  • Brand
  • LG Display
  • Model P/N
  • LM315WR4-SSA1
  • Diagonal Size
  • 32.0"
  • Panel Type
  • a-Si TFT-LCD, LCM
  • Resolution
  • 3840(RGB)×2160, UHD  139PPI
  • Pixel Format
  • RGB Vertical Stripe
  • Active Area
  • 697.306(W)×392.234(H) mm
  • Bezel Opening
  • -
Outline(mm)
Luminance
Viewing Angle
Good View at
Color Depth
Mass
Refresh Rate
713.1(W)×415.25(H)×22.2(D)
750 (Typ.)(cd/m²)
89/89/89/89 (Typ.)(CR≥10)
Symmetry
1.07B   97% DCI-P3
6.37Kgs (Typ.)
144Hz
Treatment
Contrast Ratio
Work Mode
Response
Backlight
Used for
Touchscreen
Antiglare (Haze 25%), Hard coating (3H)
1000 : 1 (Typ.) (TM)
IPS, Normally Black, Transmissive
4 (Typ.)(G to G) ms
WLED , 30K hours , No Driver
  •
  •
  •
Without
Signal TypeeDP (8 Lanes) , HBR2 (5.4G/lane) , 120 pins Connector
Voltage Supply10.0V (Typ.)
Max. RatingsStorage Temp.: -20 ~ 60 °C    Operating Temp.: 0 ~ 50 °C


LG Display LM315WR4-SSA1 Mechanical Details

Pixel Features :
Resolution
3840(RGB)×2160, UHD
Dot Pitch(mm)
0.06053×0.18159 (H×V)
Pixel Format
RGB Vertical Stripe
Pixel Pitch(mm)
0.18159×0.18159 (H×V)  [139PPI]
Mechanical Size :
Active Area(mm)
697.306(H) × 392.234(V)
Bezel Area(mm)
-
Outline Dim.(mm)
713.1(H) × 415.25(V)
Depth(mm)
14.65/22.2
Outline Features :
Form Style
Flat Rectangle
Shape Style
3-side borderless
Aspect Ratio
16:9 (H:V)
Orientation
Landscape type
Mounting :
Rear mounting holes
Other Spec :
Weight
6.37Kgs (Typ.)
Treatment
Antiglare (Haze 25%), Hard coating (3H)
  • Disclaimer : Inputted by panelook engineers according to datasheet, but we cannot guarantee the spec listed is entirely correct.
  •  Back to Top

LG Display LM315WR4-SSA1 Optical Details

Basic Information :
Luminance(cd/m²)
750 (Typ.), HDR1000
Contrast Ratio
1000:1 (Typ.) (Transmissive)
Viewing Angle
89/89/89/89 (Typ.)(CR≥10)
Display Mode
IPS, Normally Black, Transmissive
Best View on
Symmetry
Response(ms)
4 (Typ.)(G to G)
Color Performance :
White Coordinate
Wx:0.313; Wy:0.329
Display Colors
1.07B (8-bit + Hi-FRC)
Color Temperature
6485K
White Uniformity
1.33 (Max.)(9 points)
1931 Color Gamut :
NTSC Ratio
94%
sRGB
100% coverage
Adobe RGB
87% coverage
DCI-P3
97% coverage
Rec.2020
71% coverage
Remarks
sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)
