LG 21.3inch LB213QS1-SL01 2048x2560 1100nit 72% 1800:1 true 10bit LVDs ATW C/Top

$0

LG 21.3inch LB213QS1-SL01 2048x2560 1100nit 72% 1800:1 true 10bit LVDs ATW C/Top

Product Description

LG 21.3inch LB213QS1-SL01 2048x2560 1100nit 72% 1800:1 true 10bit LVDs ATW C/Top


  • Brand
  • LG Display
  • Model P/N
  • LB213QS1-SL01
  • Diagonal Size
  • 21.3"
  • Panel Type
  • a-Si TFT-LCD, LCM
  • Resolution
  • 2048(RGB)×2560  153PPI
  • Pixel Format
  • RGB Vertical Stripe
  • Active Area
  • 337.92(W)×422.4(H) mm
  • Bezel Opening
  • -
  • Luminance
    1100 cd/m² (Typ.)
  • Contrast Ratio
    1800:1 (Typ.) (TM)
  • View Direction
    Symmetry
  • Response Time
    -
  • Viewing Angle
    89/89/89/89 (Typ.)(CR≥10)
  • Operating Mode
    IPS NEO, Normally Black, Transmissive
  • Support Color
    1.07B
  • Light Source
    WLED , W/O Driver
  • Weight
    -
  • Designed For
  • Frame Rate
    -
  • Touch Panel
    Without
  • Interface Type
  • LVDS (4 ch, 10-bit) Connector
  • Power Supply
  • 12.0V (Typ.)
  • Environment
  • Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C

  • LG Display LB213QS1-SL01 Mechanical Features

    Panel Size :21.3"
    Pixel Features :Pixel FormatPixel ConfigurationPixel Pitch (mm)Dot Pitch (mm)
    2048(RGB)×2560RGB Vertical Stripe0.165×0.165  [153PPI]0.055×0.165
    Mechanical Size :Active Area (mm)Bezel Area (mm)Outline Dimension (mm)Outline Depth (mm)
    337.92(H) × 422.4(V)---
    Outline Features :Form FactorOrientationAspect RatioShape Style
    Flat RectanglePortrait type4:5 (H:V)
    Mounting :Rear mounting
    Other Detail :WeightPanel CoverTreatment
    --Antiglare, Hard coating
    • Disclaimer : The above parameters are not from the datasheet, only as a reference, please use with caution!
    •  Back to Top

  • LG Display LB213QS1-SL01 Optical Features

    Basic Information :Luminance (cd/m²)Viewing Angle (L/R/U/D)Response Time (ms)
    1100 (Typ.)89/89/89/89 (Typ.)(CR≥10)-
    Best View onDisplay ModeContrast Ratio
    SymmetryIPS NEO, Normally Black, Transmissive1800 : 1 (Typ.) (Transmissive)
    Dispaly Color :Color TemperatureDisplay ColorsWhite Coordinate
    -1.07B (10-bit)-
    Performance :3D TechSunlight VisibilityReflectance
    -Sunlight Readable-
