LG 31inch LB310FTM-SPA1 Lcd Screen 4200x2800 1200nit 72% 1500:1 true 10bit eDP ATW C/To

$0

LG 31inch LB310FTM-SPA1 Lcd Screen 4200x2800 1200nit 72% 1500:1 true 10bit eDP A

Product Description

LG 31inch LB310FTM-SPA1 Lcd Screen 4200x2800 1200nit 72% 1500:1 true 10bit eDP ATW C/To


  • Brand
  • LG Display
  • Model P/N
  • LB310FTM-SPA1
  • Diagonal Size
  • 31.0"
  • Panel Type
  • a-Si TFT-LCD, LCM
  • Resolution
  • 4200(RGB)×2800  163PPI
  • Pixel Format
  • RGB Vertical Stripe
  • Active Area
  • 652.88(W)×435.12(H) mm
  • Bezel Opening
  • 656.1(W)×438.508(H) mm
Outline(mm)
Luminance
Viewing Angle
Good View at
Color Depth
Mass
Refresh Rate
676.9(W)×459.7(H)×26.3(D)
1200 (Typ.)(cd/m²)
89/89/89/89 (Typ.)(CR≥10)
Symmetry
1.07B   72% NTSC
6.4/6.5Kgs (Typ./Max.)
60Hz
Treatment
Contrast Ratio
Work Mode
Response
Backlight
Used for
Touchscreen
Antiglare, Hard coating (3H)
1500 : 1 (Typ.) (TM)
IPS, Normally Black, Transmissive
14 (Typ.)(G to G) ms
WLED , 50K hours , No Driver
Without
Signal TypeeDP (4 Lanes) , HBR2 (5.4G/lane) , 60 pins Connector
Voltage Supply10.0V (Typ.)
Max. RatingsStorage Temp.: -20 ~ 60 °C    Operating Temp.: 0 ~ 50 °C

LG Display LB310FTM-SPA1 Mechanical Details

Pixel Features :
Number of Pixel
4200(RGB)×2800
Arrangement
RGB Vertical Stripe
Dot Pitch(W×H)
0.0518×0.1554 mm
Pixel Pitch(W×H)
0.1554×0.1554 mm  [163PPI]
Physical Size :
Active Viewing
652.88(W)×435.12(H) mm
Overall Dim.
676.9(W)×459.7(H) mm
Bezel Opening
656.1(W)×438.508(H) mm
Overall Depth
21/26.3 (Typ./Max.) mm
Outline Features :
Form Shape
Flat Rectangle
Orientation
Landscape type
Aspect Ratio(W:H)
15:10
Shape Style
Fixation :
Side mounting holes, Rear mounting holes
Other Detail :
Mass
6.4/6.5Kgs (Typ./Max.)
Surface
Antiglare, Hard coating (3H)
  • Disclaimer : Inputted by panelook engineers according to datasheet, but we cannot guarantee the spec listed is entirely correct.
  •  Back to Top

LG Display LB310FTM-SPA1 Optical Details

Basic Information :
Luminance
1200 cd/m² (Typ.)
Contrast Ratio
1500:1 (Typ.) (Transmissive)
Good View at
Symmetry
Response Speed
14 (Typ.)(G to G) ms
Viewing Angle
89/89/89/89 (Typ.)(CR≥10)
Operating Mode
IPS, Normally Black, Transmissive
Color Performance :
Chromaticity
Wx:0.297; Wy:0.317
Support Color
1.07B (10-bit)
Color Temperature
7601K
White Variation
1.25 (Max.)(11 points)
1931 Color Gamut :
NTSC Ratio
76%
sRGB
98% coverage
Adobe RGB
76% coverage
DCI-P3
79% coverage
Rec.2020
57% coverage
Remarks
sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)
Dispaly Performance :
Outdoor Visibility
Sunlight Readable
Transmissivity
-
