EV121WXM-N16 BOE 1280x800 12.1 Inch IPS TFT LCD Display Panels 30 Pin 12.1 Inch LCD Screen LCD Modules

1280x800 12.1 Inch IPS TFT LCD Display Panels EV121WXM-N16 30 Pin 12.1 Inch LCD

Product Description

Type

IPS

Display Size

12.1"

Place of Origin

Beijing, China

Supplier Type

Original factory supply

Brand Name

BOE

Resolution

1280(RGB)*800, WXGA 124PPI

Viewing Angle

85/85/85/85

Brightness

400 cd/m²

Contrast Ratio

1000:1

Interface

LVDS(1 ch, 8-bit) , 30 pins

Backlight Type

WLED , 50K hours , with LED driver

Operating Temperature

-20 ~ +70 (℃)

Response time

30ms

Power Consumption

About 6.38W

Work Mode

ADS, Normally Black, Transmissive

Selling Units

Single item

Single package size

28.0X22.0X5.0 cm

Single gross weight

0.600 kg
