BOE 10.4 Inch SVGA Antiglare TFT LCD Display 800x600 Resolution 20 Pin LCD Panel LED Driver 800x600 Resolution LCD Panel

$0

BA104S01-300 BOE 10.4 Inch SVGA Antiglare TFT LCD Display 800x600 Resolution 20

Product Description

BA104S01-300 BOE 10.4 Inch SVGA Antiglare TFT LCD Display 800x600 Resolution 20 Pin LCD Panel LED Driver 800x600 Resolution 20 Pin LCD Panel


Key attributes

Type
TFT
Display Size
10.4 inch
Place of Origin
Beijing, China
Supplier Type
Original Factory Agent
Brand Name
BOE
Size
10.4 inch
Resolution
800(RGB)x600 , SVGA
Viewing angle
80/80/65/75 (Typ.)(CR≥10) Left/Right/Up/ Down
Brightness
350 nits
Contrast Ratio
800:1
Interface Type
LVDS (1 ch, 6/8-bit) , 20 pins , Connector
Backlight Type
WLED , 30K hours , With LED Driver
Operate temperature
-20 ~ +70 (°C)
Response time
30ms
Application
Industrial Use ,Medical imaging

Packaging and delivery

Selling Units
Single item
Single package size
28X22X6 cm
Single gross weight
0.500 kg
