GT080X0M-N12 BOE 8 Inch LCD Panel 1024x768 XGA LVDS 40 Pin LCD Display Screen 8 Inch Portable TFT LCD Module

$0

GT080X0M-N12 BOE 8 Inch LCD Panel 1024x768 XGA LVDS 40 Pin LCD Display Screen 8

Product Description

GT080X0M-N12 BOE 8 Inch LCD Panel 1024x768 XGA LVDS 40 Pin LCD Display Screen 8 Inch Portable TFT LCD Module


Key attributes

Type
TFT
Display Size
8 inch
Place of Origin
Beijing, China
Supplier Type
Original Factory Agent
Brand Name
BOE
Backlight Type
LED
Resolution
1024x768, XGA 160PPI
Brightness
400 cd/m² (Typ.)
Operating Temperature
-20 ~ 70 °C
Brand
BOE
Display Type
IPS
Mounting Type
Panel Mounting
Screen Size
8.0"
Communication Interface
LVDS (1 ch, 8-bit) , 40 pins FPC
View angle
75/75/75/70 (Typ.)
contrast ratio
500:1
Backlight
3S11P WLED , Without Driver
Display mode
TN, Normally White, Transmissive
Display Colors
16.2M 50% NTSC
Total Consumption
1.87W

Packaging and delivery

Selling Units
Single item
Single package size
25X20X10 cm
Single gross weight
0.400 kg
