BOE BA104S01-100 10.4'' 800x600 TFT LCD Modules Screen Panel LVDS 20 Pins Vital Sign ECG Display Screen

$0

BOE 10.4'' 800x600 TFT LCD Modules Screen Panel BA104S01-100 LVDS 20 Pin

Product Description

BOE 10.4'' 800x600 TFT LCD Modules Screen Panel BA104S01-100 LVDS 20 Pins Vital Sign ECG Display 10.4 Inch LCD Display



Key attributes

Type
TFT
Display Size
10.4 inch
Place of Origin
Zhejiang, China
Supplier Type
Manufacturer
Brand Name
BOE
Backlight Type
LED
Resolution
800x600, SVGA 96PPI
Brightness
500 cd/m² (Typ.)
Operating Temperature
-20 ~ 70 °C
Brand
BOE
Display Type
TFT
Mounting Type
Panel Mounting
Screen Size
10.4"
Communication Interface
LVDS (1 ch, 6/8-bit) , 20 pins Connector
Viewing Angle
70/70/60/70 (Typ.)
Contrast Ratio
800:1
Backlight
6S6P WLED , 50K hours , Without Driver
Display Mode
TN, Normally White, Transmissive
Color Depth
262K/16.7M 50% NTSC
Response Time
30ms
Power Consumption
4.084W (Typ.)
Weight
0.3KG
