MCG156FDLAAQNN-AN20 Kyocera 15.6" IPS LCD PANEL 1920×1080 450nits WLED LVDS 40pins

MCG156FDLAAQNN-AN20 Kyocera 15.6" IPS LCD PANEL 19201080 450nits WLED LVDS

Product Description

System Category :	LCD/OLED/EPD Flat Panel > TFT-LCD Panel
Brand :	Kyocera
Series :	MCG156FDLAAQNN
Model :	MCG156FDLAAQNN-AN20
Keywords Desc. :	Kyocera 15.6" IPS LCM 1920×1080 450nits WLED LVDS 40pins
Product Class :	Graphic Display
Product Tags :	Color TFT-LCD, Wide Temperature LCD, IPS LCD
Application :	Industrial
Panel Type :	LTPS TFT-LCD
Panel Composition :	LCM
Panel Size :	15.6"
Resolution :	1920×1080
Aspect Ratio :	16:9 (W:H)
Form Factor :	Flat Rectangle
Active Area :	344.16 (W) × 193.59 (H) mm (A.A)
Outline Dimension :	363.8 (W) × 215.9 (H) mm
Max. Depth :	9.8 mm
LC Family :	IPS
Polarizer :	Transmissive
Brightness :	450 (Typ.)
Contrast Ratio :	800:1 (Typ.)
Viewing Angle :	85/85/85/85 (Typ.)(CR≥10) (L/R/U/D)
Viewing Direction :	Symmetry
Display Colors :	16.2M
Backlight Type :	WLED
Interface Type :	LVDS
Interface Pins :	40 Pins
Touch Panel :	Without
Operating Temp. :	-30 ~ 85 °C
Storage Temp. :	-40 ~ 90 °C
