TCG104VGLAAANN-AN00 Kyocera 10.4" TN LCD PANEL 640×480 400nits WLED TTL 40pins

TCG104VGLAAANN-AN00 Kyocera 10.4" TN LCD PANEL 640480 400nits WLED TTL 40pi

Product Description

System Category :	LCD/OLED/EPD Flat Panel > TFT-LCD Panel
Brand :	Kyocera
Series :	TCG104VGLAAANN
Model :	TCG104VGLAAANN-AN00
Keywords Desc. :	Kyocera 10.4" TN LCM 640×480 400nits WLED TTL 40pins
Product Class :	Graphic Display
Product Tags :	Color TFT-LCD
Application :	Industrial
Panel Type :	a-Si TFT-LCD
Panel Composition :	LCM
Panel Size :	10.4"
Resolution :	640×480
Aspect Ratio :	4:3 (W:H)
Form Factor :	Flat Rectangle
Active Area :	211.2 (W) × 158.4 (H) mm (A.A)
Outline Dimension :	240.7 (W) × 180.2 (H) mm
Max. Depth :	9.5 mm
LC Family :	TN
Polarizer :	Transmissive
Brightness :	400 (Typ.)
Contrast Ratio :	500:1 (Typ.)
Viewing Angle :	70/70/60/70 (Typ.)(CR≥10) (L/R/U/D)
Viewing Direction :	6 o'clock
Display Colors :	262K
Backlight Type :	WLED
Interface Type :	TTL
Interface Pins :	40 Pins
Touch Panel :	Without
Operating Temp. :	-20 ~ 70 °C
Storage Temp. :	-30 ~ 80 °C
