TCG084SVLQAPNN-AN20-SA Kyocera 8.4" IPS LCD PANEL 800×600 400nits WLED LVDS 30pins 70Hz

TCG084SVLQAPNN-AN20-SA Kyocera 8.4" IPS LCD PANEL 800600 400nits WLED LVDS

Product Description

System Category :	LCD/OLED/EPD Flat Panel > TFT-LCD Panel
Brand :	Kyocera
Series :	TCG084SVLQAPNN
Model :	TCG084SVLQAPNN-AN20-SA
Keywords Desc. :	Kyocera 8.4" IPS LCM 800×600 400nits WLED LVDS 30pins 70Hz
Product Class :	Graphic Display
Product Tags :	Color TFT-LCD, IPS LCD
Application :	Industrial
Panel Type :	a-Si TFT-LCD
Panel Composition :	LCM
Panel Size :	8.4"
Resolution :	800×600
Aspect Ratio :	4:3 (W:H)
Form Factor :	Flat Rectangle
Active Area :	170.4 (W) × 127.8 (H) mm (A.A)
Outline Dimension :	199.5 (W) × 147.4 (H) mm
Max. Depth :	9.5 mm
LC Family :	IPS
Polarizer :	Transmissive
Brightness :	400 (Typ.)
Contrast Ratio :	500:1 (Typ.)
Viewing Angle :	85/85/85/85 (Typ.)(CR≥10) (L/R/U/D)
Viewing Direction :	Symmetry
Display Colors :	262K/16.7M
Backlight Type :	WLED
Interface Type :	LVDS
Interface Pins :	30 Pins
Touch Panel :	Without
Operating Temp. :	-20 ~ 70 °C
Storage Temp. :	-30 ~ 80 °C
