MCG121XGLBBQNN-AN21 Kyocera 12.1" IPS LCD PANEL 1024×768 500nits WLED LVDS 20pins

$0

MCG121XGLBBQNN-AN21 Kyocera 12.1" IPS LCD PANEL 1024768 500nits WLED LVDS 2

Product Description

MCG121XGLBBQNN-AN21 Kyocera 12.1" IPS LCD PANEL 1024×768 500nits WLED LVDS 20pins

System Category :LCD/OLED/EPD Flat Panel > TFT-LCD Panel
Brand :Kyocera
Series :MCG121XGLBBQNN
Model :MCG121XGLBBQNN-AN21
Keywords Desc. :Kyocera 12.1" IPS LCM 1024×768 500nits WLED LVDS 20pins
Product Class :Graphic Display
Product Tags :Color TFT-LCD, Wide Temperature LCD, IPS LCD
Application :Industrial
Panel Type :a-Si TFT-LCD
Panel Composition :LCM
Panel Size :12.1"
Resolution :1024×768
Aspect Ratio :4:3 (W:H)
Form Factor :Flat Rectangle
Active Area :245.76 (W) × 184.32 (H) mm (A.A)
Outline Dimension :260.5 (W) × 204 (H) mm
Max. Depth :8.96 mm
LC Family :IPS
Polarizer :Transmissive
Brightness :500 (Typ.)
Contrast Ratio :1000:1 (Typ.)
Viewing Angle :89/89/89/89 (Typ.)(CR≥10) (L/R/U/D)
Viewing Direction :Symmetry
Display Colors :262K/16.7M
Backlight Type :WLED
Interface Type :LVDS
Interface Pins :20 Pins
Touch Panel :Without
Operating Temp. :-30 ~ 70 °C
Storage Temp. :-40 ~ 80 °C
