Product Description

System Category :	LCD/OLED/EPD Flat Panel > TFT-LCD Panel
Brand :	Kyocera
Series :	TCG104VGLCHANN
Model :	TCG104VGLCHANN-AN40
Keywords Desc. :	Kyocera 10.4" TN LCM 640×480 1100nits WLED LVDS 20pins
Product Class :	Graphic Display
Product Tags :	Color TFT-LCD, Wide Temperature LCD, High Brightness LCD, Sunlight Readable LCD
Application :	Industrial, Outdoor High Brightness
Panel Type :	a-Si TFT-LCD
Panel Composition :	LCM
Panel Size :	10.4"
Resolution :	640×480
Aspect Ratio :	4:3 (W:H)
Form Factor :	Flat Rectangle
Active Area :	211.2 (W) × 158.4 (H) mm (A.A)
Outline Dimension :	230 (W) × 180.2 (H) mm
Max. Depth :	11 mm
LC Family :	TN
Polarizer :	Transmissive
Brightness :	1100 (Typ.)
Contrast Ratio :	500:1 (Typ.)
Viewing Angle :	70/70/60/70 (Typ.)(CR≥10) (L/R/U/D)
Display Colors :	16.7M
Backlight Type :	WLED
Interface Type :	LVDS
Interface Pins :	20 Pins
Touch Panel :	Without
Operating Temp. :	-30 ~ 80 °C
Storage Temp. :	-30 ~ 80 °C
