TCG070WVLQEPFB-AA20 Kyocera 7" IPS LCD PANEL 800×480 280nits WLED LVDS 30pins RTP

TCG070WVLQEPFB-AA20 Kyocera 7" IPS LCD PANEL 800480 280nits WLED LVDS 30pin

Product Description

System Category :	LCD/OLED/EPD Flat Panel > TFT-LCD Panel
Brand :	Kyocera
Series :	TCG070WVLQEPFB
Model :	TCG070WVLQEPFB-AA20
Keywords Desc. :	Kyocera 7" IPS LCM 800×480 280nits WLED LVDS 30pins RTP
Product Class :	Graphic Display
Product Tags :	Color TFT-LCD, Resistive Touch LCD, IPS LCD
Application :	Industrial
Panel Type :	a-Si TFT-LCD
Panel Composition :	LCM
Panel Size :	7"
Resolution :	800×480
Aspect Ratio :	15:9 (W:H)
Form Factor :	Flat Rectangle
Active Area :	152.4 (W) × 91.44 (H) mm (A.A)
Outline Dimension :	165 (W) × 104.4 (H) mm
Max. Depth :	11.2 mm
LC Family :	IPS
Polarizer :	Transmissive
Brightness :	280 (Typ.)
Contrast Ratio :	650:1 (Typ.)
Viewing Angle :	85/85/85/85 (Typ.)(CR≥10) (L/R/U/D)
Viewing Direction :	Symmetry
Display Colors :	262K/16.2M
Backlight Type :	WLED
Interface Type :	LVDS
Interface Pins :	30 Pins
Touch Panel :	4-wire Resistive Touch
Operating Temp. :	-20 ~ 70 °C
Storage Temp. :	-30 ~ 80 °C
