TCG057VGLDFAFA-GA00 Kyocera 5.7" TN LCD PANEL 640×480 320nits WLED TTL 33pins RTP

TCG057VGLDFAFA-GA00 Kyocera 5.7" TN LCD PANEL 640480 320nits WLED TTL 33pin

Product Description

System Category :	LCD/OLED/EPD Flat Panel > TFT-LCD Panel
Brand :	Kyocera
Series :	TCG057VGLDFAFA
Model :	TCG057VGLDFAFA-GA00
Keywords Desc. :	Kyocera 5.7" TN LCM 640×480 320nits WLED TTL 33pins RTP
Product Class :	Graphic Display
Product Tags :	Color TFT-LCD, Resistive Touch LCD
Application :	Industrial
Panel Type :	a-Si TFT-LCD
Panel Composition :	LCM
Panel Size :	5.7"
Resolution :	640×480
Aspect Ratio :	4:3 (W:H)
Form Factor :	Flat Rectangle
Active Area :	115.2 (W) × 86.4 (H) mm (A.A)
Outline Dimension :	134.5 (W) × 103.4 (H) mm
Max. Depth :	10.15 mm
LC Family :	TN
Polarizer :	Transmissive
Brightness :	320 (Typ.)
Contrast Ratio :	500:1 (Typ.)
Viewing Angle :	80/80/80/80 (Typ.)(CR≥5) (L/R/U/D)
Display Colors :	262K
Backlight Type :	WLED
Interface Type :	TTL
Interface Pins :	33 Pins
Touch Panel :	4-wire Resistive Touch
Operating Temp. :	-20 ~ 70 °C
Storage Temp. :	-30 ~ 80 °C
