TM080SDH01-41 Tianma 8" TN LCD PANEL 800×600 250nits WLED TTL 50pins

$0

TM080SDH01-41 Tianma 8" TN LCD PANEL 800600 250nits WLED TTL 50pins

Product Description

TM080SDH01-41 Tianma 8" TN LCD PANEL 800×600 250nits WLED TTL 50pins

System Category :LCD/OLED/EPD Flat Panel > TFT-LCD Panel
Brand :Tianma
Series :TM080SDH
Model :TM080SDH01-41
Keywords Desc. :Tianma 8" TN LCM 800×600 250nits WLED TTL 50pins
Product Class :Graphic Display
Product Tags :Color TFT-LCD
Application :Industrial
Panel Type :a-Si TFT-LCD
Panel Composition :LCM
Panel Size :8"
Resolution :800×600
Aspect Ratio :4:3 (W:H)
Form Factor :Flat Rectangle
Active Area :162 (W) × 121.5 (H) mm (A.A)
Outline Dimension :183 (W) × 141 (H) mm
Max. Depth :5.9 mm
LC Family :TN
Polarizer :Transmissive
Brightness :250 (Typ.)
Contrast Ratio :800:1 (Typ.)
Viewing Angle :70/70/60/70 (Typ.)(CR≥10) (L/R/U/D)
Viewing Direction :6 o'clock
Display Colors :262K/16.7M
Backlight Type :WLED
Interface Type :TTL
Interface Pins :50 Pins
Touch Panel :Without
Operating Temp. :-20 ~ 70 °C
Storage Temp. :-30 ~ 80 °C
