TM104TDGP10 Tianma 10.4" IPS LCD PANEL 1024×768 450nits WLED LVDS 20pins

$0

TM104TDGP10 Tianma 10.4" IPS LCD PANEL 1024768 450nits WLED LVDS 20pins

Product Description

TM104TDGP10 Tianma 10.4" IPS LCD PANEL 1024×768 450nits WLED LVDS 20pins

System Category :LCD/OLED/EPD Flat Panel > TFT-LCD Panel
Brand :Tianma
Series :TM104TDGP
Model :TM104TDGP10
Keywords Desc. :Tianma 10.4" IPS LCM 1024×768 450nits WLED LVDS 20pins
Product Class :Graphic Display
Product Tags :Color TFT-LCD, IPS LCD
Application :Industrial
Panel Type :a-Si TFT-LCD
Panel Composition :LCM
Panel Size :10.4"
Resolution :1024×768
Aspect Ratio :4:3 (W:H)
Form Factor :Flat Rectangle
Active Area :210.432 (W) × 157.824 (H) mm (A.A)
Outline Dimension :230 (W) × 175.8 (H) mm
Max. Depth :9.06 mm
LC Family :IPS
Polarizer :Transmissive
Brightness :450 (Typ.)
Contrast Ratio :1200:1 (Typ.)
Viewing Angle :85/85/85/85 (Typ.)(CR≥10) (L/R/U/D)
Viewing Direction :Symmetry
Display Colors :262K/16.7M
Backlight Type :WLED
Interface Type :LVDS
Interface Pins :20 Pins
Touch Panel :Without
Operating Temp. :-20 ~ 70 °C
Storage Temp. :-30 ~ 80 °C
