P0700WVN1MB01 Tianma 7" TN LCD PANEL 800×480 450nits WLED TTL 50pins

P0700WVN1MB01 Tianma 7" TN LCD PANEL 800480 450nits WLED TTL 50pins

Product Description

System Category :	LCD/OLED/EPD Flat Panel > TFT-LCD Panel
Brand :	Tianma
Series :	P0700WVN1MB
Model :	P0700WVN1MB01
Keywords Desc. :	Tianma 7" TN LCM 800×480 450nits WLED TTL 50pins
Product Class :	Graphic Display
Product Tags :	Color TFT-LCD
Application :	Industrial
Panel Type :	a-Si TFT-LCD
Panel Composition :	LCM
Panel Size :	7"
Resolution :	800×480
Aspect Ratio :	16:9 (W:H)
Form Factor :	Flat Rectangle
Active Area :	154.08 (W) × 85.92 (H) mm (A.A)
Outline Dimension :	164.9 (W) × 100 (H) mm
Max. Depth :	6 mm
LC Family :	TN
Polarizer :	Transmissive
Brightness :	450 (Typ.)
Contrast Ratio :	800:1 (Typ.)
Viewing Angle :	80/80/60/80 (Typ.)(CR≥10) (L/R/U/D)
Viewing Direction :	6 o'clock
Display Colors :	16.7M
Backlight Type :	WLED
Interface Type :	TTL
Interface Pins :	50 Pins
Touch Panel :	Without
Operating Temp. :	-20 ~ 70 °C
Storage Temp. :	-30 ~ 80 °C
