NV156FHM-N43 BOE 15.6" IPS LCD PANEL 1920×1080 300nits WLED eDP 30pins BOE0681 BOE065F

$0

NV156FHM-N43 BOE 15.6" IPS LCD PANEL 19201080 300nits WLED eDP 30pins BOE06

Product Description

NV156FHM-N43 BOE 15.6" IPS LCD PANEL 1920×1080 300nits WLED eDP 30pins BOE0681 BOE065F


System Category :LCD/OLED/EPD Flat Panel > TFT-LCD Panel
Brand :BOE
Series :NV156FHM-N4
Model :NV156FHM-N43
Keywords Desc. :BOE 15.6" IPS LCM 1920×1080 300nits WLED eDP 30pins BOE0681 BOE065F
Product Class :Graphic Display
Product Tags :Color TFT-LCD, IPS LCD
Application :Healthcare, Laptop
Panel Type :a-Si TFT-LCD
Panel Composition :LCM
Panel Size :15.6"
Resolution :1920×1080
Aspect Ratio :16:9 (W:H)
Form Factor :Flat Rectangle
Active Area :344.16 (W) × 193.59 (H) mm (A.A)
Outline Dimension :359.5 (W) × 223.8 (H) mm
Max. Depth :3.2 mm
LC Family :IPS
Polarizer :Transmissive
Brightness :300 (Typ.)
Contrast Ratio :800:1 (Typ.)
Viewing Angle :85/85/85/85 (Typ.)(CR≥10) (L/R/U/D)
Viewing Direction :Symmetry
Display Colors :262K
Backlight Type :WLED
Interface Type :eDP
Interface Pins :30 Pins
Touch Panel :Without
Operating Temp. :0 ~ 50 °C
Storage Temp. :-20 ~ 60 °C
