EV240WUM-N10 BOE 24" IPS LCD PANEL 1920×1200 600nits WLED LVDS 30pins

EV240WUM-N10 BOE 24" IPS LCD PANEL 19201200 600nits WLED LVDS 30pins

Product Description

System Category :	LCD/OLED/EPD Flat Panel > TFT-LCD Panel
Brand :	BOE
Series :	EV240WUM
Model :	EV240WUM-N10
Keywords Desc. :	BOE 24" IPS LCM 1920×1200 600nits WLED LVDS 30pins
Product Class :	Graphic Display
Product Tags :	Color TFT-LCD, IPS LCD
Application :	Medical Imaging
Panel Type :	a-Si TFT-LCD
Panel Composition :	LCM
Panel Size :	24"
Resolution :	1920×1200
Aspect Ratio :	16:10 (W:H)
Form Factor :	Flat Rectangle
Active Area :	518.4 (W) × 324 (H) mm (A.A)
Outline Dimension :	546.4 (W) × 352 (H) mm
Max. Depth :	12.2 mm
LC Family :	IPS
Polarizer :	Transmissive
Brightness :	600 (Typ.)
Contrast Ratio :	1000:1 (Typ.)
Viewing Angle :	89/89/89/89 (Typ.)(CR≥10) (L/R/U/D)
Viewing Direction :	Symmetry
Display Colors :	16.7M
Backlight Type :	WLED
Interface Type :	LVDS
Interface Pins :	30 Pins
Touch Panel :	Without
Operating Temp. :	0 ~ 50 °C
Storage Temp. :	-20 ~ 60 °C
