DV430FHM-NN1 BOE 43" IPS LCD Panel 1920×1080 400nits WLED LVDS 51pins

DV430FHM-NN1 BOE 43" IPS LCD Panel 19201080 400nits WLED LVDS 51pins

Product Description

System Category :	LCD/OLED/EPD Flat Panel > TFT-LCD Panel
Brand :	BOE
Series :	DV430FHM
Model :	DV430FHM-NN1
Keywords Desc. :	BOE 43" IPS LCM 1920×1080 400nits WLED LVDS 51pins
Product Class :	Graphic Display
Product Tags :	Color TFT-LCD, IPS LCD
Application :	Digital Signage
Panel Type :	a-Si TFT-LCD
Panel Composition :	LCM
Panel Size :	43"
Resolution :	1920×1080
Aspect Ratio :	16:9 (W:H)
Form Factor :	Flat Rectangle
Active Area :	940.896 (W) × 529.254 (H) mm (A.A)
Outline Dimension :	961.7 (W) × 550.1 (H) mm
Max. Depth :	27.7 mm
LC Family :	IPS
Polarizer :	Transmissive
Brightness :	400 (Typ.)
Contrast Ratio :	1200:1 (Typ.)
Viewing Angle :	89/89/89/89 (Typ.)(CR≥10) (L/R/U/D)
Viewing Direction :	Symmetry
Display Colors :	16.7M
Backlight Type :	WLED
Interface Type :	LVDS
Interface Pins :	51 Pins
Touch Panel :	Without
Operating Temp. :	0 ~ 50 °C
Storage Temp. :	-20 ~ 60 °C
