AT070TN83 V.1 Innolux 7" TN LCD Panel 800×480 400nits WLED TTL 40pins

AT070TN83 V.1 Innolux 7" TN LCD Panel 800480 400nits WLED TTL 40pins

Product Description

System Category :	LCD/OLED/EPD Flat Panel > TFT-LCD Panel
Brand :	Innolux
Series :	AT070TN83
Model :	AT070TN83 V.1
Keywords Desc. :	Innolux 7" TN LCM 800×480 400nits WLED TTL 40pins
Product Class :	Graphic Display
Product Tags :	Color TFT-LCD
Application :	Digital Photo Frame, MP3 PMP, Portable DVD Player
Panel Type :	a-Si TFT-LCD
Panel Composition :	LCM
Panel Size :	7"
Resolution :	800×480
Aspect Ratio :	15:9 (W:H)
Form Factor :	Flat Rectangle
Active Area :	152.4 (W) × 91.44 (H) mm (A.A)
Outline Dimension :	165 (W) × 104 (H) mm
Max. Depth :	5.8 mm
LC Family :	TN
Polarizer :	Transmissive
Brightness :	400 (Typ.)
Contrast Ratio :	1000:1 (Typ.)
Viewing Angle :	70/70/50/70 (Typ.)(CR≥10) (L/R/U/D)
Viewing Direction :	6 o'clock
Display Colors :	262K
Backlight Type :	WLED
Interface Type :	TTL
Interface Pins :	40 Pins
Touch Panel :	Without
Operating Temp. :	-20 ~ 70 °C
Storage Temp. :	-30 ~ 80 °C
