G104ACJ-L01 Innolux 10.4" IPS LCD Panel 960×1280 900nits WLED LVDS 50pins

G104ACJ-L01 Innolux 10.4" IPS LCD Panel 9601280 900nits WLED LVDS 50pins

Product Description

System Category :	LCD/OLED/EPD Flat Panel > TFT-LCD Panel
Brand :	Innolux
Series :	G104ACJ
Model :	G104ACJ-L01
Keywords Desc. :	Innolux 10.4" IPS LCM 960×1280 900nits WLED LVDS 50pins
Product Class :	Graphic Display
Product Tags :	Color TFT-LCD, Wide Temperature LCD, High Brightness LCD, Sunlight Readable LCD, IPS LCD
Application :	Industrial, Outdoor High Brightness
Panel Type :	a-Si TFT-LCD
Panel Composition :	LCM
Panel Size :	10.4"
Resolution :	960×1280
Aspect Ratio :	3:4 (W:H)
Form Factor :	Flat Rectangle
Active Area :	158.4 (W) × 211.2 (H) mm (A.A)
Outline Dimension :	173.4 (W) × 228.7 (H) mm
Max. Depth :	14.27 mm
LC Family :	IPS
Polarizer :	Transmissive
Brightness :	900 (Typ.)
Contrast Ratio :	1000:1 (Typ.)
Viewing Angle :	85/85/85/85 (Typ.)(CR≥10) (L/R/U/D)
Viewing Direction :	Symmetry
Display Colors :	16.7M
Backlight Type :	WLED
Interface Type :	LVDS
Interface Pins :	50 Pins
Touch Panel :	Without
Operating Temp. :	-40 ~ 85 °C
Storage Temp. :	-40 ~ 90 °C
