G104XCE-LH1 Innolux 10.4" IPS LCD Panel 1024×768 1000nits WLED LVDS 30pins

$0

G104XCE-LH1 Innolux 10.4" IPS LCD Panel 1024768 1000nits WLED LVDS 30pins

Product Description

G104XCE-LH1 Innolux 10.4" IPS LCD Panel 1024×768 1000nits WLED LVDS 30pins


System Category :LCD/OLED/EPD Flat Panel > TFT-LCD Panel
Brand :Innolux
Series :G104XCE
Model :G104XCE-LH1
Keywords Desc. :Innolux 10.4" IPS LCM 1024×768 1000nits WLED LVDS 30pins
Product Class :Graphic Display
Product Tags :Color TFT-LCD, Wide Temperature LCD, High Brightness LCD, Sunlight Readable LCD, IPS LCD
Application :Industrial, Outdoor High Brightness
Panel Type :a-Si TFT-LCD
Panel Composition :LCM
Panel Size :10.4"
Resolution :1024×768
Aspect Ratio :4:3 (W:H)
Form Factor :Flat Rectangle
Active Area :210.432 (W) × 157.824 (H) mm (A.A)
Outline Dimension :225.5 (W) × 176.3 (H) mm
Max. Depth :9.2 mm
LC Family :IPS
Polarizer :Transmissive
Brightness :1000 (Typ.)
Contrast Ratio :1000:1 (Typ.)
Viewing Angle :88/88/88/88 (Typ.)(CR≥10) (L/R/U/D)
Viewing Direction :Symmetry
Display Colors :262K/16.2M
Backlight Type :WLED
Interface Type :LVDS
Interface Pins :30 Pins
Touch Panel :Without
Operating Temp. :-30 ~ 85 °C
Storage Temp. :-30 ~ 85 °C
