G101ICE-LM1 Innolux 10.1" IPS LCD Panel 1280×800 350nits WLED LVDS 30pins

$0

G101ICE-LM1 Innolux 10.1" IPS LCD Panel 1280800 350nits WLED LVDS 30pins

Product Description

G101ICE-LM1 Innolux 10.1" IPS LCD Panel 1280×800 350nits WLED LVDS 30pins


System Category :LCD/OLED/EPD Flat Panel > TFT-LCD Panel
Brand :Innolux
Series :G101ICE
Model :G101ICE-LM1
Keywords Desc. :Innolux 10.1" IPS LCM 1280×800 350nits WLED LVDS 30pins
Product Class :Graphic Display
Product Tags :Color TFT-LCD, IPS LCD
Application :Industrial
Panel Type :a-Si TFT-LCD
Panel Composition :LCM
Panel Size :10.1"
Resolution :1280×800
Aspect Ratio :16:10 (W:H)
Form Factor :Flat Rectangle
Active Area :216.96 (W) × 135.6 (H) mm (A.A)
Outline Dimension :227.42 (W) × 147.69 (H) mm
Max. Depth :4.85 mm
LC Family :IPS
Polarizer :Transmissive
Brightness :350 (Typ.)
Contrast Ratio :800:1 (Typ.)
Viewing Angle :89/89/89/89 (Typ.)(CR≥10) (L/R/U/D)
Viewing Direction :Symmetry
Display Colors :262K/16.7M
Backlight Type :WLED
Interface Type :LVDS
Interface Pins :30 Pins
Touch Panel :Without
Operating Temp. :-10 ~ 60 °C
Storage Temp. :-20 ~ 70 °C
