NJ070NA-23A Innolux 7" TN LCD Panel 1024×600 500nits WLED LVDS 40pins

NJ070NA-23A Innolux 7" TN LCD Panel 1024600 500nits WLED LVDS 40pins

Product Description

System Category :	LCD/OLED/EPD Flat Panel > TFT-LCD Panel
Brand :	Innolux
Series :	NJ070NA
Model :	NJ070NA-23A
Keywords Desc. :	Innolux 7" TN LCM 1024×600 500nits WLED LVDS 40pins
Product Class :	Graphic Display
Product Tags :	Color TFT-LCD
Application :	Automotive Display
Panel Type :	a-Si TFT-LCD
Panel Composition :	LCM
Panel Size :	7"
Resolution :	1024×600
Aspect Ratio :	16:9 (W:H)
Form Factor :	Flat Rectangle
Active Area :	154.214 (W) × 85.92 (H) mm (A.A)
Outline Dimension :	164.9 (W) × 100 (H) mm
Max. Depth :	5.1 mm
LC Family :	TN
Polarizer :	Transmissive
Brightness :	500 (Typ.)
Contrast Ratio :	800:1 (Typ.)
Viewing Angle :	80/80/60/70 (Typ.)(CR≥10) (L/R/U/D)
Viewing Direction :	6 o'clock
Display Colors :	262K/16.7M
Backlight Type :	WLED
Interface Type :	LVDS
Interface Pins :	40 Pins
Touch Panel :	Without
Operating Temp. :	-20 ~ 70 °C
Storage Temp. :	-30 ~ 80 °C
