AUO G170HAN01.0 17" IPS LCM 1920×1920 600nits WLED eDP 40pins

$0

AUO G170HAN01.0 17" IPS LCM 19201920 600nits WLED eDP 40pinsSpecificationSy

Product Description

  • AUO G170HAN01.0 17" IPS LCM 1920×1920 600nits WLED eDP 40pins


  • Specification

System Category :LCD/OLED/EPD Flat Panel > TFT-LCD Panel
Brand :AUO
Series :G170HAN01
Model :G170HAN01.0
Keywords Desc. :AUO 17" IPS LCM 1920×1920 600nits WLED eDP 40pins
Product Class :Graphic Display
Product Tags :Color TFT-LCD, Square LCD, IPS LCD
Application :Industrial, Square Display
Panel Type :a-Si TFT-LCD
Panel Composition :LCM
Panel Size :17"
Resolution :1920×1920
Aspect Ratio :1:1 (W:H)
Form Factor :Flat Rectangle
Active Area :305.28 (W) × 305.28 (H) mm (A.A)
Outline Dimension :325.01 (W) × 319.33 (H) mm
Max. Depth :12.2 mm
LC Family :IPS
Polarizer :Transmissive
Brightness :600 (Typ.)
Contrast Ratio :1000:1 (Typ.)
Viewing Angle :89/89/89/89 (Typ.)(CR≥10) (L/R/U/D)
Viewing Direction :Symmetry
Display Colors :16.7M
Backlight Type :WLED
Interface Type :eDP
Interface Pins :40 Pins
Touch Panel :Without
Operating Temp. :-20 ~ 60 °C
Storage Temp. :-20 ~ 70 °C
